    Fuel Hose - PIPER OIL HOSE 7840E

Large bore marine diesel exhaust hose. Fuel, oil and hydraulic fluids with up to 50% aromatics. Suitable for exhaust gas from water cooled stationary or marine diesel engines.

Click to enlarge - Large bore marine diesel exhaust hose. Fuel, oil and hydraulic fluids with up to 50% aromatics. Suitable for exhaust gas from water cooled stationary or marine diesel engines.


Click to enlarge - Large bore marine diesel exhaust hose. Fuel, oil and hydraulic fluids with up to 50% aromatics. Suitable for exhaust gas from water cooled stationary or marine diesel engines.
Colour Black
Cover NBR/PVC blended rubber. Abrasion, ozone, hydrocarbon and fire resistant
Lining NBR rubber
Reinforcement High tensile textile cords with embeded steel helix wires.
Specification To Lloyds 99/000027 APP. DNV S-2472 APP
Remarks Nordic Boat Standard MC9
Application For use on marine diesel engines
Special Features Safety factor 5:1
Temperature -30C + 100C

Bore Size ODWorking PressureWeightBend Radius
InchmmmmBarKg/mmm

2"516031.25153
2 1/2"637231.52189
3"768632.47228
4"10211233.27306
5"12714135.26381

Back to previous page Enquire about this product
