Steam & Boss Type Hose Fittings
-
STEAM & HIGH PRESSURE COUPLINGS
|
|
|
|
|
|
Designed for use with steam and compressed air applications. Ground joint type and washer type. Four or six bolt clamp depending on size. Designed for steam service to +232ºC
|
|
|
Notes
|
For use with interlocking finger clamps. Material : Plated Malleable Iron.
Washer is a composite of Kevlar and is used in the washer type coupling only.
Can be supplied with NPT threads
|
| SIZE | COMPLETE | STEM | WING NUT | FEMALE | MALE | WASHER |
| INCH | FEMALE COUPLING | ONLY | ONLY | SPUD | SPUD | |
| 1/2" - 05 | 700- 05 | 701- 05 | 702- 05 | 703- 05 | 704- 05 | 705- 05 |
| 3/4" - 07 | 700- 07 | 701- 07 | 702- 07 | 703- 07 | 704- 07 | 705- 07 |
| 1" - 10 | 700- 10 | 701- 10 | 702- 10 | 703- 10 | 704- 10 | 705- 10 |
| 1 1/4" - 12 | 700- 12 | 701- 12 | 702- 12 | 703- 12 | 704- 12 | 705- 12 |
| 1 1/2 - 15 | 700- 15 | 701- 15 | 702- 15 | 703- 15 | 704- 15 | 705- 15 |
| 2" - 20 | 700- 20 | 701- 20 | 702- 20 | 703- 20 | 704- 20 | 705- 20 |
| 2 1/2 - 25 | 700- 25 | 701- 25 | 702- 25 | 703- 25 | 704- 25 | 705- 25 |
| 3" - 30 | 700- 30 | 701- 30 | 702- 30 | 703- 30 | 704- 30 | 705- 30 |
| 4" - 40 | 700- 40 | 701- 40 | 702- 40 | 703- 40 | 704- 40 | - |
|
|
|
|
