Designation Ltd - 46 years and still going strong! - Water Hose - ATLANTIC 2105 - Atlantic 2105 is a very heavy duty hose designed for use in mines and quarries. This hose has a special EPDM liner that is designed for slurries and abrasives at high temperatures. The hose range has a constant working pressure through all sizes. Very robust and end are normally either swaged or stainless banded.

Atlantic 2105 is a very heavy duty hose designed for use in mines and quarries. This hose has a special EPDM liner that is designed for slurries and abrasives at high temperatures. The hose range has a constant working pressure through all sizes. Very robust and end are normally either swaged or stainless banded.

Click to enlarge - Atlantic 2105 is a very heavy duty hose designed for use in mines and quarries. This hose has a special EPDM liner
that is designed for slurries and abrasives at high temperatures. The hose range has a constant working pressure through all sizes.
Very robust and end are normally either swaged or stainless banded.

Colour	Wrapped black cover/Black lining
Cover	SBR/EPDM compound
Lining	Abraision resistant EPDM Synthetic compound
Reinforcement	High strength multiple textile yarns. Double sprung wire helix
Specification	Normally swaged or banded flange connections. Safety ratio 3:1 on all sizes
Temperature	-30ºC +100ºC

ID	ID	OD	WP	WP	Weight
Inch	mm	mm	psi	bar	Kg/m
3"	76	90	300	20	2.56
4"	102	116	300	20	2.85
5"	140	141	300	20	4.67
6"	152	168	300	20	5.03
8"	203	225	300	20	15.83
10"	254	278	300	20	22.00


Back to previous page	Enquire about this product
