    Oil Hose - BRENT OIL/FUEL HOSE 5604

Oil/fuel suction discharge hose with embedded helix wires. Designed for use in heavy duty applications with an aromatic content not exceeding 50% This hose is designed to be used with swaged end fittings.

Click to enlarge - Oil/fuel suction discharge hose with embedded helix wires. Designed for use in heavy duty applications with an aromatic content not exceeding 50%

This hose is designed to be used with swaged end fittings.


Click to enlarge - Oil/fuel suction discharge hose with embedded helix wires. Designed for use in heavy duty applications with an aromatic content not exceeding 50%

This hose is designed to be used with swaged end fittings.
Colour Wrapped black conductive cover
Cover Conductice chloroprene abrasion, ozone and flame resistant.
Lining Black conductive NBR rubber
Reinforcement Textile yarns and double wire helix
Specification To EN 1761:1991 TRbf 131/2
Remarks Normally yellow transfer stripe
Application For transfer and suction of oil.
Temperature -30C +70C

IDIDODWPWPWeightVacuumAvailability
InchmmmmpsibarKg/m%See under
2"5167240161.79984 weeks
2 1/2"6379240161.82908 weeks
3"7692240162.39904 weeks
4"102116240162.83904 weeks
6"152172240168.70904 weeks
8"2032302401612.98906 weeks
